Analog Digital Converter (ADC) printed card for a spectrum analyser.

Model 3571A from Hewlett Packard.

Manufactured : 1978 in USA.

PCB (Printed Card Board) listed as A22.

Main components :

-High precision R/2R : Array of thin film of Nickel Chrome resistors on glass, array of thick film resistors,

-Active discrete components such as bipolar transistors, glass diodes,

-Actives Integrated components such as Medium Scale Integrated (MSI) ; Transistor Transistor Logic (TTL) series.

PCB made of FR4 (Flame Retardant 4) substrate with gold protection.

High resolution photo with 600 dpi obtained with Agfa Scanner 1212U
